Part Numbers

Port Size
Volume Film Thickness 3″ 4″ 6″ 8″
2L 4MIL 4003339 4003340
5L 4MIL 4003341 4003342
10L 4MIL 4003343 4003344 4003345 4003346
15L 4MIL 4003347 4003348 4003349 4003350
20L 6MIL 4003351 4003352 4003353 4003354
25L 6MIL 4003355 4003356 4003357 4003358
40L 10MIL 4003359 4003360 4003361
50L 10MIL 4003362 4003363 4003364
100L 10MIL 4003365 4003366 4003367



* includes RheoPac, Weloc Clamp, and Dust Cap


RheoPacs

Rheo Flexibles provides a wide range of single use transfer containers. The RheoPac family of products offer an excellent alternative to stainless intermediate transfer containers. The RheoPac can be designed with many valve and bag design configurations.



SoliValve®

The RheoPac can be equipped with an integrated SoliValve® passive that will allow the RheoPac to dock to Visval SoliValve® dosing technology. This SoliValve® technology uses a split cone valve to provide automatic docking and high containment during powder transfer from the RheoPac to the receiving container.


SoliValve100

MTS Dispensing Workstation

Rheo offers a GMP dispensing workstation for filling RheoPacs. This system has a built-in Drum Tipper as well as an integrated load cell system that allows for weighing directly into the RheoPac.



Transport Cart

Rheo can provide GMP transfer carts to provide an easy means to transfer the filled bags from the dispensing station to the transfer point downstream in the process.



Column Lift

Rheo can provide a GMP column lift that can be used to lift and position one or multiple RheoPacs into position above the receiving vessel.



Accessories

Many accessories can be provided with our RheoPacs to create a complete high containment system, some of these accessories include:

  • Weloc Clamps
  • Tri-Lock Clamps
  • Gaskets


Film Collage

RheoFlex™ Film

RheoPacs are constructed from Polyethylene (with a non-migratory anti-stat) that has been tested and is fully compliant with all regulatory requirements. The film comes with a full documentation package tied to the labeled part number.



Testing Center

Rheo is able to do full mock-ups as well as containment performance verification in our Rheo Testing Center. Partner with our engineering team and we can produce a prototype system for your application and verify performance to build confidence in the implementation phase.


Rheo Testing Center
